1/2" Copper Pipe Wall Mount Flange

1/2" ID Copper Pipe Wall Mount Flange; Three-screw.

We stick standard 1/2" ID copper pipe/tubing up in a lot of places to hang spray bottles, pliers, cables, you name it. This is an over-built, over-designed wall-mount flange with significant support material on one section for underneath the pipe.

The screw holes are for 0.135" screws (~#6) and the (flat) countersink is an additional 0.0625" (1/16"). That happened to fit a bunch of extra screws; we'll upload a version that use a normal beveled wood screw head.

NOTE: Unlike some closet pole hangers, this is currently meant to have the pipe inserted into both flanges then mounted in-place, e.g., semi-permanent. We'll design a version that has one end as a drop-in and a fully-backed wall plate, while maintained the support bulge.

It is a snug fit; we'll upload a version with (slightly) looser tolerances. We prefer the snug fit, but it may not suit all purposes. At 10% infill this is still pretty sturdy, but if you're hanging
