360° Hinge
by EnginEli
735
Downloads
672
Likes
0
Makes
Hi everyone! this is my design for a hinge that allows 360° rotation between the two plates.
If you are interested in understanding the mechanism in more detail, you can give a look at my IG page: @engineli_3d.
One pecularity on this hinge is that the center of rotation between the plates is not fixed, but changes in every configuration of the system.
To build a single hinge you will need eight M3 screws (M3x16 for the big one, M3x10 for te Mini one).
Then you can use it as you like! to build anything or even just as a stress relief!
Happy printing to everyone!
If you are interested in understanding the mechanism in more detail, you can give a look at my IG page: @engineli_3d.
One pecularity on this hinge is that the center of rotation between the plates is not fixed, but changes in every configuration of the system.
To build a single hinge you will need eight M3 screws (M3x16 for the big one, M3x10 for te Mini one).
Then you can use it as you like! to build anything or even just as a stress relief!
Happy printing to everyone!
