Armrest adjustment for IKEA Markus
von krotny
11
Downloads
16
Likes
0
Makes
Spacers for adjusting position of the IKEA Markus armrests.
The armrests can be either pulled back (by ~10cm) or both: lowered and pulled back. For the former, it's enough to use the spacers with M8 screws (and nuts). Screws length should be at least 30mm (for the thin variant) or 40mm (for the thicker and more rigid variant). For the latter, the optional support may be printed and used with a distancer to fix a position (mounting holes have radius=11.5mm; I used two screws with octagonal heads and a distancer as showed in the pictures).
The original models were created with FreeCad 0.19 and sliced for printing with Cura 4.5.
The armrests can be either pulled back (by ~10cm) or both: lowered and pulled back. For the former, it's enough to use the spacers with M8 screws (and nuts). Screws length should be at least 30mm (for the thin variant) or 40mm (for the thicker and more rigid variant). For the latter, the optional support may be printed and used with a distancer to fix a position (mounting holes have radius=11.5mm; I used two screws with octagonal heads and a distancer as showed in the pictures).
The original models were created with FreeCad 0.19 and sliced for printing with Cura 4.5.
