Customizable Compasses
120
Download
129
Likes
0
Makes
A tool that is used as a circle arc at the corners of the board when not using a normal compass.
It sets angular and ruler dimensions and hole spacing for the marker.
Use when an arc drawing tool in corners where the center of the circle is exactly at the end of the pad.
How to edit/set model:
An angle is set in the model, so it is not only possible to use a right angle with a sharp edge, but also for other angles, including a semi-circle with an arc centered on the edge.
Try:
The right angle is suitable for arches on already rounded corners. > 90 ° is suitable for a generally sharp corner. A 180 ° is suitable for semi-circles on the side.
It sets angular and ruler dimensions and hole spacing for the marker.
Use when an arc drawing tool in corners where the center of the circle is exactly at the end of the pad.
How to edit/set model:
An angle is set in the model, so it is not only possible to use a right angle with a sharp edge, but also for other angles, including a semi-circle with an arc centered on the edge.
Try:
The right angle is suitable for arches on already rounded corners. > 90 ° is suitable for a generally sharp corner. A 180 ° is suitable for semi-circles on the side.
