Door Hinge for KETER shed
di oaba
3
Download
4
Likes
0
Makes
I bought the KETER shed with a completly broken door hinge.
They did not supply the replacement for this.
So I was designing a replacement.
I had to remove the remnant of the old hinge and glue this one on place with Loctite.
I was filling up the other hinge`s cavity with hot glue to add more rigidity.
I was giving a little wide tolerance for easy fit.
I printid it out of PETG 0.3mm layer hight and 40% infill
I was adding support only for the bottom!
They did not supply the replacement for this.
So I was designing a replacement.
I had to remove the remnant of the old hinge and glue this one on place with Loctite.
I was filling up the other hinge`s cavity with hot glue to add more rigidity.
I was giving a little wide tolerance for easy fit.
I printid it out of PETG 0.3mm layer hight and 40% infill
I was adding support only for the bottom!
