Emergency Stop case

di Silasderkreative

9 Download

8 Likes

0 Makes

This is a box suitable for this emergency stop switch: https://www.mouser.de/ProductDetail/EAO/84-50200020?qs=2pKMaj72wiGPozmAoEeJ0A== .

Furthermore I used this cable gland: https://www.conrad.de/de/p/lapp-skindicht-mini-m-8x1-kabelverschraubung-m8-messing-nickel-1-st-526841.html .

The thread of the cable gland is an M8x1. In my 3D model it is intended to screw the cable gland into the hole provided. The matching thread is in the hole. So you don't need a nut to counter it.

All necessary files are available. If you want to change the component you can download the Inventor file and find an assembly. If you want to upload your modified part here please link me below as a remix.
