Photogrammetry rotary platform
by mhoffacker
3
Downloads
2
Likes
0
Makes
Photogrammetry platform driven by a NEMA17 stepper motor.
The shaft for the middle gear is not printed but requires a 4mm metal pin.
Data available on OnShape: https://cad.onshape.com/documents/3d0474ddb7b4aa770b81a9bf/w/2c011a971aa1893663168029/e/0341dc7d9305ea28a0f8dbb3
The Top part is available as one single STEP / STL file and as separate files for the clip and the gear. I had to change the printing orientation of the clip to archive the required flexibility.
Add some silicon grease before mounting the top part on the bottom part and also to the gears.
All holes are slightly to small, I drilled it to the required size. Do not forget to increase the wall count.
The shaft for the middle gear is not printed but requires a 4mm metal pin.
Data available on OnShape: https://cad.onshape.com/documents/3d0474ddb7b4aa770b81a9bf/w/2c011a971aa1893663168029/e/0341dc7d9305ea28a0f8dbb3
The Top part is available as one single STEP / STL file and as separate files for the clip and the gear. I had to change the printing orientation of the clip to archive the required flexibility.
Add some silicon grease before mounting the top part on the bottom part and also to the gears.
All holes are slightly to small, I drilled it to the required size. Do not forget to increase the wall count.
