I was designing a chest structure for a robot I was going to design/build, but I decided to go a different route.
I posted this because I figured it may be of use to someone else.
_______________________________________________________________
This could be used as a stand for the Animatronic Neck Mechanism (https://www.thingiverse.com/thing:4796648), since it's made to work with it.
The servo slot is designed to house a 60kg/cm Servo. Just place the servo in the (60kg) Servo holder.stl and slide it into the square slot in the L/R-part.
Sketchup file is also included.
___________________________________________________________________
The whole thing is 34cm long and 22.6cm tall.
The large square parts that run through the R/L-parts are 3x3cm
___________________________________________________________________
I posted this because I figured it may be of use to someone else.
_______________________________________________________________
This could be used as a stand for the Animatronic Neck Mechanism (https://www.thingiverse.com/thing:4796648), since it's made to work with it.
The servo slot is designed to house a 60kg/cm Servo. Just place the servo in the (60kg) Servo holder.stl and slide it into the square slot in the L/R-part.
Sketchup file is also included.
___________________________________________________________________
The whole thing is 34cm long and 22.6cm tall.
The large square parts that run through the R/L-parts are 3x3cm
___________________________________________________________________
