Sorting Trays for SMD Integrated Circuits

1 Downloads
2 Likes
0 Makes
Go to Model
SummaryToday I had a weird idea: What if I had a kind of sorting album for all of my ICs, Resistors and other electronic components that I've accumulated over the years - instead of putting the tape strips into little compartment boxes?Then I remembered that "Sample Books" are readily available for order on Aliexpress - those are simple binders with binder sheets included, where you can slip the tape strips into. (Not unlike those sheets you can buy for trading cards)After I ordered one of those I sorted my components and wondered what I should do with loose parts, either salvaged from old electronics or those that never came on a tape strip - and the answer is this thing here.After approximating the measurements of the binder sheets, I think they should fit nicely - Just put your parts inside the printed thing and tape them down with some clear scotch tape, so they won't fall out as easily.Print SettingsPrinter: Anet A8 Resolution: 0.2 Infill: 25-45% Filament: noname P
Category
Electronics
Source
MakerWorld
Published
Updated
What you need to print this: Beginner Low confidence
Single piece
Supports 1/3
Assembly 0/3
Settings 1/3
Bed size 0/3
Post-process 0/3
Printer
FDM / FFF
File format
STL
Material
Software
Cura, PrusaSlicer, or similar
