USB security box

1 Descargas
7 Likes
0 Makes
Ver Modelo
Got tired of the wife and kids stealing my USB cables. I found another design on thingiverse but I wasn't happy with it, so I designed this one. No more cables have migrated to anyone else's devices. Confirmed snug fit with NOOT & RAVPOWER 60W 6 port chargers. Supports only needed for the mains power cord entrance. Has 3 CSK holes in the box for wall mount. #6 screw seems to be a good fit but I haven't actually mounted it. Lid is secured to box with #4 screws. I've included a picture of the screws I used for the lid.

For reference, the USB chargers I'm using are approx. (LxWxH) 4in X 2.72in X 1.18in or 101.6mm X 69.09mm X 29.97mm.

NOOT model: NP60W (https://www.amzn.com/B075Y614Q3)

RAVPower model: RP-PC028 (https://www.amzn.com/B00OQ19QYA)

1/28/20 - Encountered a few thicker cables that required filing to fit previous 3.7mm slots. Updated model to increase cable slot width to 4.5mm.

Fuente
Thingiverse
Lo que necesitas para imprimir: Intermedio Baja confianza
Pieza única Tornillería requerida
Soportes 1/3
Ensamblaje 0/3
Ajustes 1/3
Tamaño de cama 0/3
Postproceso 1/3
Impresora
FDM / FFF
Formato de archivo
STL
Material
Polycarbonate
Postprocesado
Tornillería
Software
Cura, PrusaSlicer o similar
