Waffle
por Charles_Xavier
186
Descargas
126
Likes
3
Makes
Have you ever wanted to 3D print a waffle, but were unable to find an anatomically correct model? It's happened to all of us! I was completely dissatisfied with this, and set out to create my own waffle model.
Behold! Six inches in diameter, with 64 cavities for butter and syrup, and a 1/4" thickness connecting sections, this waffle has been optimized for 3D printing. A perfect 15° draft for internal features ensures this waffle would NEVER get stuck in the waffle maker!
Future versions may include a 4x4 grid of syrup wells, slightly inset and radiused top-walls, and perhaps a simulated ring of flash where the parting line would be. I intentionally left out the flash in this model to allow for printing without supports, but if people want it, I can work it into the revision.
Behold! Six inches in diameter, with 64 cavities for butter and syrup, and a 1/4" thickness connecting sections, this waffle has been optimized for 3D printing. A perfect 15° draft for internal features ensures this waffle would NEVER get stuck in the waffle maker!
Future versions may include a 4x4 grid of syrup wells, slightly inset and radiused top-walls, and perhaps a simulated ring of flash where the parting line would be. I intentionally left out the flash in this model to allow for printing without supports, but if people want it, I can work it into the revision.
